Trimless Mud Ring for 4" Pearl Round Trimless : NPR-TLMR-4R

No Image
Available

Image may not reflect selected features

Trimless Mud Ring for 4" Pearl Round Trimless (NPR-TLMR-4R) by Nora

Allows 4" Pearl round trimless retrofits to be installed even no exposed flange and no extension beyond ceiling plane. Mud ring attaches to drywall and requires professional drywall finishing.

Compatible Trimless:
NPR-4RTLA: 4" 120V Pearl LED Round Trimless Adjustable Retrofit
NPR-4RTLNDC: 4" 120V Pearl LED Round Trimless Retrofit Downlight
NPR-4RTSLA: 4" 120V Pearl LED Round Trimless Adjustable Slot Retrofit
NPRLV-4RTLA: 4" 12V Pearl LED Round Trimless Adjustable Retrofit
NPRLV-4RTLNDC: 4" 12V Pearl LED Round Trimless Retrofit Downlight
NPRLV-4RTSLA: 4" 12V Pearl LED Round Trimless Adjustable Slot Retrofit

Downloads

Instruction Sheet

Product Specification

Item #

NPR-TLMR-4R

Dimensions

Height: 1.10"

Width: 7.30"

Additional product details

Vendor Item #

NPR-TLMR-4R
